3. Installation

This section will guide you through the installation and general setup of the Robotiq Palletizing Solution.
Before installing:
Read and understand the safety instructions related to the Palletizing Solution. Refer to the Safety section.
l
Verify the package according to the scope of delivery and the order.
l
Make sure to have the required parts, equipment and tools listed in the scope of delivery.
l
Make sure to meet the recommended environmental conditions.
l
Robotiq uses the metric system. Unless otherwise specified, all dimensions in this manual are in millimeters.
Do not turn on or operate the Palletizing Solution before making sure the device is firmly anchored and the
l
machine area is cleared.
When assembling or moving the Solution, make sure there is enough vertical and horizontal clearance in order
l
to avoid material damage and bodily injury.
Make sure that the air supply source is secured.
l
Failure to properly secure and install the equipment can result in material damage and bodily injury.
l
If the installation is not performed in compliance with the manufacturer's instructions, the warranty will be void.
l
Make sure to follow all workplace safety rules and regulations when installing, operating, servicing, inspecting and maintaining
l
the Robotiq Palletizing Solution.
Always wear all recommended personal protective equipment in accordance with the safety standards of the workplace,
l
including but not limited to:
Safety glasses
o
Hearing protection
o
Hard hats
o
Steel-toe boots
o
Always use proper safety measures when working with tools that have sharp edges, pinching surfaces, or heat sources.
l
Always lift heavy objects with the legs, not the back. Ask for help or find alternative solutions if a heavy object cannot safely be
l
lifted by a single person.
NOTICE
WARNING
