7. Specifications

This manual uses the metric system. Unless specified, all dimensions are in millimeters.

7.1. Technical Dimensions

7.1.1. Linear Axis Base with Control Box

7.1.2. PowerPick20/30 Vacuum Gripper (Optional)

For the technical dimensions of the PowerPick20/30 Vacuum Gripper, please refer to the Technical Dimensions section of the
PowerPick20/30 user manual, available at support.robotiq.com.
Fig. 7-1: Linear Axis Base with Control Box- Technical Dimensions
NOTICE
AX20/AX30 Palletizing Solution
