2 x 360 mm cable ties
l
1 x Pneumatic adapter 1/2 BSPP (1/2 G) to 1/2 NPT (included but optional)
l
1 x Material Handling Copilot software license dongle
l
1 x 4-port USB hub
l
1 x USB-to-Ethernet adapter
l
1 x Ethernet cable (300 mm)
l
1 x Installation tool kit
l
1 x 1/2 in concrete drill bit
l
1 x 5/8 in concrete drill bit
l
1 x 15/16 socket, ½" square drive
l
1 x 8 mm hex (allen) bit socket, ⅜" square drive
l
1 x Robot installation plate kit
l
1 x Robot installation plate
l
6 x M10 x 40 mm socket head cap screws (blue dyed)
l
1 x M10 spacer
l
1 x PowerPick20/30 Vacuum Gripper standard kit (optional)
l
1 x PowerPick20/30 Vacuum Generation Unit
l
1 x Mounting bracket and filter-regulator assembly
l
1 x M12-12 pin I/O cable (3 m)
l
1 x PowerPick20/30 Vacuum Gripper (default configuration)
l
1 x Large suction cup bracket assembly
l
Air tubing
l
Tools and hardware for installation on AX20/30
l

3.2. Required Tools and Equipment

The following tools are not included, but required to install the Palletizing Solution:
Forklift or pallet jack (minimum fork length of 1220 mm [48 in])
l
Hoisting equipment (minimum payload capacity of 600 kg [1300 lb])
l
Metric set of hex wrenches and / or ratchet wrench with socket set (up to 19 mm)
l
Metric set of hex L-Key (Allen) (up to 6 mm)
l
#2 Phillips screwdriver or #2 Phillips bit with Power screwdriver (recommended for uncrating)
l
2.5 mm slotted screwdriver
l
