Binary Monitor; 3-Word Monitor - Omron SYSMAC CQM1-ID212 Operation Manual

Compatible Programming Consoles

3-6-15 Binary Monitor

1, 2, 3...

3-6-16 3-Word Monitor

1, 2, 3...
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This operation is used to monitor the ON/OFF status of any word's 16 bits. It
is possible in any mode.
RUN MONITOR
OK OK
1. Monitor the status of the desired word according to the procedure described
in 3-6-13 Bit, Digit, Word Monitor. The desired word should be leftmost on
the display if 2 or more words are being monitored.
2. Press the SHIFT and then the MONTR Key to begin binary monitoring. The
ON/OFF status of the selected word's 16 bits will be shown along the bottom
of the display. A 1 indicates a bit is on, and a 0 indicates it is off.
SHIFT MONTR
The status of force-set bits is indicated by "S", and the status of a force-reset
bits is indicated by "R", as shown below.
Note a) The status of displayed bits can be changed at this point. Refer to
3-6-22 Binary Data Modification for details.
b) The Up or Down Arrow Key can be pressed to display the status of
the previous or next word's bits.
3. Press the CLR Key to end binary monitoring and return to the normal moni-
toring display.
Press the SHIFT+CLR Keys to end monitoring altogether.
This operation is used to monitor the status of three consecutive words. It is
possible in any mode.
RUN MONITOR
OK OK
1. Monitor the status of the first of the three words according to the procedure
described in 3-6-13 Bit, Digit, Word Monitor.
If 2 or more words are being monitored, the desired first word should be left-
most on the display.
2. Press the EXT Key to begin 3-word monitoring. The status of the selected
word and the next two words will be displayed, as shown below. In this case,
DM 0000 was selected.
Note The status of the displayed words can be changed at this point. Refer
to 3-6-19 3-word Data Modification.
3. The Up and Down Arrow Keys can be used to shift one address up or down.
↓
PROGRAM
OK
C100 MONTR
1111111111111111
C100 MONTR
0000S0100R0110SR
Force-set bit Force-reset bit
PROGRAM
OK
D0002D0001D0000
EXT
0123 4567 89AB
D0003D0002D0001
↑
ABCD 0123 4567
Section 3-4
95
