CPU Unit

2-1-5 Dimensions and Weights

Dimensions
CPU Unit Front View
120
Weights

2-1-6 Memory Cassette

Memory Cassette Installation Follow the procedure below to install a Memory Cassette in the CPU Unit.
Caution
!
1, 2, 3...
10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
If the PC power supply is already turned on when a Peripheral Device is attached
to the PC, the PC will stay in the same mode it was in before the peripheral
device was attached. If the Programming Console is connected, the PC will
enter the mode set on the Programming Console's mode selector once the
password has been entered.
The following diagrams show the dimensions of the CPU Unit and right End
Cover, which covers the Unit at the far right side of the PC. All dimensions are in
millimeters.
CPU Unit Side View
2
110 115.7
Note The depth is the same for all Units.
The CQM1-CPU11-E weighs 520 g max.; the CQM1-CPU21-E and
CQM1-CPU41-EV1, 530 g max. All the other CPU Units weigh 600 g max.
Four Memory Cassettes are available as accessories to store the program or PC
Setup. When pin 2 of the CPU Unit's DIP switch is ON, the contents of the
Memory Cassette will be transferred to the CPU Unit automatically at start-up.
Memory Clock Function
EEPROM
No
Yes
No
Yes
EPROM No
Yes
Always turn off power to the CQM1 before installing or removing a Memory Cas-
sette.
1. Remove the mounting bracket from inside the memory cassette compart-
ment.
End Cover Front View
107
Model
The Programming Console is
CQM1-ME04K
used to write to EEPROM.
CQM1-ME04R
(4K words)
The Programming Console is
CQM1-ME08K
used to write to EEPROM.
CQM1-ME08R
(8K words)
CQM1-MP08K A PROM Writer is used to write
to EPROM.
CQM1-MP08R
Section 2-1
13.5
