Compatible Programming Consoles
Changing Displays
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The following diagram shows which keys to press in order to change Program-
ming Console displays.
Example mode display (connected to PC)
{PROGRAM}
CLR
Initial programming display
00000
Various operational displays
Note When cancelling an operation or beginning operation, press the CLR Key sev-
eral times to return to the initial display.
After the SHIFT Key is pressed, changing the mode by means of the mode-
change switch will cause the mode to change while retaining the current display.
When switching between RUN and PROGRAM, first go into MONITOR and
press the SHIFT Key again.
Section
BZ The CQM1's operating
mode will be displayed.
SHIFT CLR
(or switch modes)
Press several times.
CLR
(See note.)
3-4
81
