SYSMAC-CPT Precautions

3-6-14 Differentiation Monitor

1, 2, 3...
94
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3. Repeat step 2 up to 6 times to display the next addresses to be monitored.
B
CONT
SHIFT 1 MONTR
#
DM MONTR
If 4 or more bits and words are being monitored, the bits and words that do
not appear on the display can be displayed by pressing the MONTR Key. If
the MONTR Key is pressed alone, the display will shift to the right.
If more than six bits and words are input, monitoring of the bit or word input
first will be canceled.
4. Press the CLR Key to stop monitoring the leftmost bit or word and clear it
from the display.
CLR
5. Press the SHIFT+CLR Keys to end monitoring altogether.
SHIFT CLR
This operation is used to monitor the up or down differentiation status of a
particular bit. It is possible in any mode.
RUN MONITOR
OK OK
1. Monitor the status of the desired bit according to the procedure described in
3-6-13 Bit, Digit, Word Monitor. If 2 or more bits are being monitored, the
desired bit should be leftmost on the display.
In this case the differentiation status of LR 00 will be monitored.
2. To specify up-differentiation monitoring, press the SHIFT and then the Up
Arrow Key. The symbols "U@" will appear.
SHIFT
To specify down-differentiation monitoring, press the SHIFT and then the
Down Arrow Key. The symbols "D@" will appear.
SHIFT
3. The buzzer will sound when the specified bit goes from off to on (for up-dif-
ferentiation) or from on to off (for down-differentiation).
4. Press the CLR Key to end differentiation monitoring and return to the normal
monitoring display.
CLR
00001 T000
^ OFF 0100
D0000 00001 T000
1234 ^ 0FF 0100
00001 T000
^ 0FF 0100
00000
CONT 00001
PROGRAM
OK
L000000108H2315
^ OFF^ OFF^
L000000108H2315
↑
U@OFF^ OFF^
L000000108H2315
↓
D@OFF^ OFF^
L000000108H2315
^ ON ^ OFF^
L000000108H2315
^ OFF^ OFF^
Section 3-3
ON
ON
ON
ON
ON
