1. Monitor (decimal, without sign) the status of the word for which the present
value is to be changed.
2. Press the CHG Key to begin decimal data modification.
3. Input the new PV and press the WRITE Key to change the PV. The operation
will end and the decimal-without-sign monitoring display will return when the
WRITE Key is pressed.
The PV can be set within a range of 0 to 65,535.
To return to the I/O monitor, multiple address monitor, or 3-word data modifi-
cation display, either press the SHIFT and TR Keys, or else press the CLR
Key.
D C
3 2 7
Note If an erroneous input is made, press the CLR Key to restore the status
prior to the input. Then enter the correct input. If an input is made out-
side of the permissible range, a buzzer will sound.
• Double-length Change
1. The PV is displayed in double length by decimal-without-sign monitoring.
2. Press the CHG Key to begin decimal data modification.
3. Input the new PV and press the WRITE Key to change the PV. The operation
will end and the double length display will return when the WRITE Key is
pressed. The PV can be set within a range of 0 to 4,294,967,295.
A A A
7 0 0
Note If an erroneous input is made, press the CLR Key to restore the status
prior to the input. Then enter the correct input. If an input is made out-
side of the permissible range, a buzzer will sound.
4. When the decimal monitoring with sign has been completed, the I/O moni-
tor, multiple address monitoring, or 3-word data modification display is
restored.
Note The I/O monitor, multiple address monitoring, or 3-word data modification dis-
play can also be restored by means of the CLR Key.
This operation is used to force bits ON (force set) or OFF (force reset) and is
useful when debugging the program or checking output wiring. It is possible
in MONITOR or PROGRAM mode only.
RUN
No
cL01
18838
PRES VAL?
CHG
cL01 18838
cL01
6 8 WRITE
32768
cL02 cL01
EXT
1234599936
PRES VAL?
CHG
cL02 1234599936
cL02 cL01
A
0 0 WRITE
0000070000
cL01 cL0200001
SHIFT TR
1170 0001^ 0FF
MONITOR PROGRAM
OK OK
