Omron SYSMAC CQM1-ID212 Operation Manual page 88

SYSMAC-CPT Precautions
Group Name
DM Transfer
PC —> Computer
(C-series PCs only)
Transfer
Computer—>PC
(C-series PCs only)
Transfer
Verify
(C-series PCs only)
Monitor
(C-series PCs only)
Go To Page
(C-series PCs only)
Read DM Addr
(CVM1 PCs only)
Copy
(CVM1 PCs only)
Fill
(CVM1 PCs only)
Print
(CVM1 PCs only)
HEX <-> ASCII
(CVM1 PCs only)
Switch Bank
Number
(CVM1 PCs only)
Save DM data
(CVM1 PCs only)
Retrieve DM data
(CVM1 PCs only)
Transfer DM
(CVM1 PCs only)
I/O Table
Transfer I/O Table
Create I/O Table
Verify I/O Table
Clear I/O Table
(CVM1 PCs only)
76
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Retrieves PC DM data to the system work area.
Writes system work area DM data to the PC.
Compares DM data between the system work area and PC.
Used to monitor DM area contents in the PC.
Reads a specified page from the DM list of the DM area in the system work area or
PC.
Reads the contents of the DM area, including the specified DM address, from the
work disk and displays it in the DM table.
Copies multiple, consecutive words of DM data to a specified destination DM
address.
Places a specified value into multiple, consecutive words of the DM area. Filling
with 0000 clears the DM words.
Prints multiple, consecutive words of DM data.
Specified inputs using hexadecimal or ASCII. The mode set will be displayed in the
top-right of the screen.
Switches editing between the standard DM and EM banks.
Saves the DM data from the work disk to the data disk or hard disk.
Retrieves the DM data on the data disk or hard disk to the work disk.
Transfers and compares DM data between the SSS and the PC.
Transfers and compares the I/O table data between the computer and PC.
Registers into the PC the I/O Units mounted on the PC and then assigns the words
to the Units.
Compares the I/O table registered in the PC against the I/O Units actually mounted
on the PC.
Deletes the I/O tables (C200H and C200HS only)
Description
Section 3-3
