Sss Capabilities; Online Operations; Offline And Online Operations - Omron SYSMAC CQM1-ID212 Operation Manual

Compatible Programming Consoles

3-1-2 Online Operations

Group Function name
ON-LINE MONITOR DATA
TRANSFER PROGRAM
ON-LINE EDIT
READ SCAN TIME
CLEAR DATA AREAS
MEMORY USAGE
Operations are also available to change display modes and search for instructions and comments.
DM DM area operations are available to transfer and compare DM data between the PC, LSS, and data
disks, and to monitor DM contents in the PC.
I/O TABLE I/O TABLE operations are used to write, transfer, and compare I/O tables between the PC and LSS.
UTILITY
FILE MEMORY
TIME CHART MONITOR
INSTRUCTION TRACE
DATA TRACE
DEBUG
XFER DATA LINK TBL
CLOCK
TRANSFER INSTR
TRANSFER PC SETUP

3-1-3 Offline and Online Operations

Group
SYSTEM SETUP The SYSTEM SETUP provides settings for the operating environment of the LSS, including the
PC that's being communicated with (including network and interface settings) and disk drive,
comment, printer, PROM Writer, and monitor settings. It also provides settings for transfer of
I/O table and data link tables to UM.
FILE MANAGEMENT FILE MANAGEMENT operations include basic file management features so that files can be
manipulated directly from the LSS. It also provides a feature for merging program files.
3-2

SSS Capabilities
