Unit Specifications
8-point Transistor Output Unit
Item
Max. Switching Capacity
Leakage Current
Residual Voltage
ON Delay
OFF Delay
No. of Outputs
Internal Current
Consumption
Service Power Supply
Weight
Alarm Output
Reset Input
(*1)
Short-circuit Protection
Circuit Configuration
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
+10%
1.0 A at 24 VDC /
–15%
4 A/Unit
0.1 mA max.
1.2 V max.
0.2 ms max.
0.8 ms max.
8 points (8 points/common, 1 circuit)
110 mA max. at 5 VDC max.
+10%
24 mA min. at 24 VDC
240 grams max.
No. of outputs 2 outputs
ALM0: Alarm output OUT 0 to 3
ALM1: Alarm output OUT 4 to 7
Output Max. switching capacity:
specifications Leakage current:
Residual voltage:
No. of inputs 2 inputs
RST0: Reset input OUT 0 to 3
RST1: Reset input OUT 4 to 7
Input Input voltage:
specifications Input current:
ON voltage:
OFF voltage:
Detection current: 2 A (minimum value), 1.6 A (typical)
Output
LED
Internal
Alarm output
Circuits
LED
560 Ω
CQM1-OD215
(3 mA  number of ON points)
/
–15%
100 mA at 24 VDC
0.1 mA max.
0.7 V max.
+10%
24 VDC
7 mA, typical (24 VDC)
16.0 VDC min.
5.0 VDC max.
COM
Overcurrent
+V
detection
circuit
OUT0
OUT07
ALM0
ALM1
RST0
3.3 kΩ
RST1
0V
Section 2-6
+10%
/
–15%
/
–15%
24 VDC
(+)
(–)
Alarm output
Reset output
65
