To 24-Vdc And 24-Vdc Input Units - Omron SYSMAC CQM1-ID212 Operation Manual

Unit Specifications

2-6-7 12 to 24-VDC and 24-VDC Input Units

Item
Input Voltage 12 to 24 VDC
Input 2.4 kΩ
Impedance
Input Current 10 mA typical (at 24 VDC)
ON Voltage 10.2 VDC min.
OFF Voltage 3.0 VDC max.
ON Delay Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
OFF Delay Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
No. of Inputs 8 points (independent commons)
Internal Current 50 mA max. at 5 VDC
Consumption
Weight 180 grams max.
Circuit
Configuration
Note The input power supply polarity may be con-
nected in either direction.
Terminal
Connections
54
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
CQM1-ID211
+10%
/
–15%
IN
2.2 kW
560 W
INc
0
B0
+ –
c0
A0
+
–
1
B1
+ –
c1
A1
+
–
2
B2
+ –
c2
A2
– +
3
B3
+ –
c3
A3
– +
4
B4
+ –
c4
A4
– +
5
B5
+ –
c5
A5
–
+
6
B6
+ –
c6
A6
–
+
7
B7
+ –
c7
A7
–
+
NC
B8
NC
A8
Note Refer to 3-1-1 Offline Operations.
+10%
24 VDC /
–15%
3.9 kΩ
6 mA typical (at 24 VDC)
14.4 VDC min.
5.0 VDC max.
Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
16 points (16 points/common, 1 circuit)
85 mA max. at 5 VDC
180 grams max.
Input
IN0
LED
to
3.9 kW
IN15
Internal
Circuits
COM
Note The input power supply polarity may be con-
nected in either direction.
–
–
Section 2-6
CQM1-ID212
Input
LED
Internal
560 W
Circuits
0
B0
1
A0
2
B1
3
A1
4
B2
5
A2
6
B3
7
A3
8
B4
9
A4
10
B5
11
A5
12
B6
13
A6
14
B7
15
A7
COM
B8
COM
A8
