Compatible Programming Consoles
Group Name
DM Go To Page
(data memory) (C-series PCs
only)
Copy
Fill
Print
Hex <—> ASCII
Save DM Data
Retrieve DM Data Retrieves the saved data disk data memory to the system work area DM area.
Read DM
Address
(CVM1 PCs only)
Switch Bank
Number
(CVM1 PCs only)
Save file
(CVM1 PCs only)
Retrieve file
(CVM1 PCs only)
I/O Table Write I/O Table
Check I/O Table
Save I/O Table
Retrieve I/O
Table
Clear I/O Table
(CVM1 PCs only)
Custom I/O Table
SIOU
(CVM1 PCs only)
Print I/O Table
(C-series PCs
only)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Displays the contents of the data memory in the system work area in pages
(units of 160 words). The data can be altered with this function.
Copies the contents of the DM area of the system work area (data memory
information).
Writes the same data to more than one data word in the system work area data
memory area.
Prints a specified range of DM words.
Specifies the display mode for the data memory contents when the work disk
data memory contents are to be altered. The display mode can be hexadecimal
or ASCII.
Writes the contents of a specified range of system work area data memory to the
data disk.
Used to display DM data from the work disk up to 160 words at a time. Displayed
data can be modified.
Used to specify the Expansion DM bank on the work disk.
Used to save file data (with an .IOM) extension from the work disk to a data disk.
Use to retrieve file data (with an .IOM extension) from a data disk to the work
disk.
Edits the I/O table in the system work area.
Checks the contents of the I/O table in the system work area.
Writes the I/O table in the system work area to a data disk.
Retrieves the I/O table data stored on a data disk to the system work area.
Used to delete the I/O table from the work disk.
Used to specify CPU Bus Unit classifications.
Prints an I/O table list.
Description
Section 3-4
73
