Unit Specifications
6-point Triac Output Unit
Item
Max. Switching Capacity
Min. Switching Capacity
Leakage Current
Residual Voltage
ON Delay
OFF Delay
No. of Outputs
Inrush current
Internal Current
Consumption
Fuse
Weight
Circuit Configuration
Terminal Connections
68
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
0.4 A at 100 to 240 VAC (50/60 Hz)
100 mA at 10 VAC
50 mA at 24 VAC
10 mA at 100 VAC
10 mA at 240 VAC
1 mA max. at 100 VAC and 2 mA max. at 200 VAC
1.5 V max. (0.4 A)
1 ms max.
Load frequency of 1/2 cycle + 1 ms max.
6 points (4 points/common, 1 circuit; 2 points/common, 1 circuit)
6 A at 100 ms
15 A at 10 ms
250 mA max. at 5 VDC
5 A at 250 V (one per common), two only used.
Fuse is not user replaceable.
240 grams max.
Output LED
Internal
Circuits
COM0
COM0
COM0
COM0
COM1
COM1
CQM1-OA222
OUT00
OUT03
COM0
Fuse
5 A
OUT04
OUT05
COM1
Fuse
5 A
0
B0
A0
1
B1
A1
2
B2
A2
3
B3
A3
4
COM0 and COM1 are not con-
B4
nected internally.
A4
5
B5
A5
NC
B6
NC
A6
NC
B7
NC
A7
NC
B8
NC
A8
Section 2-6
100 to 240 VAC
100 to 240 VAC
