Configuration

MFPs are divided into speed groups by digital function. The slew rate adjustment register configures the rise and
fall times for each MFP in the group simultaneously. The MFP slew rate can be adjusted at any time, and the
changes are applied immediately.
The MFP slew rate configuration applies to all pins in the speed group regardless of the enabled function of the pin.
For example, the speed setting is applied to a GPIO and a dedicated pin function if both are in the same MFP speed
group.
Refer to the corresponding device's data sheet "Control- and Side-Channel Typical Rise and Fall Times" section for
V timing details. The table below represents slew rate registers and the typical rise and fall times.
DDIO
Table 18.
MAX96752 MFP Slew Rate Registers
Register Bitfield Name
0x244 GPIO_SPEED_A[1:0]
GPIO_SPEED_B[1:0]

Audio

Overview

I S or TDM is available on GMSL devices. Typical use case is to send audio data from one end to the other via the
2
GMSL link. GMSL2 devices support bidirectional transmission of audio (i.e., I
channels of the serial link.
www.analog.com
Bits Default Value
1:0 0x10
3:2 0x11
Description
Controls GPIO Speed Group A (GPIO1) transition
time.
First value is for VDDIO = 1.8V, second value is
for V = 3.3V
DDIO
0 2ns, 1ns
1 4ns, 2ns
2 8ns, 4ns
3 16ns, 8ns
Controls GPIO Speed Group B (GPIO 2-13)
transition time.
First value is for VDDIO = 1.8V, second value is for
V = 3.3V
DDIO
0 2ns, 1ns
1 4ns, 2ns
2 8ns, 4ns
3 16ns, 8ns
S or TDM) over the forward and reverse
2
