Evaluates: MAX77857 (FC2QFN)
General Description
The MAX77857Q evaluation kit (EV kit) is a fully
assembled and tested printed circuit board (PCB) that
demonstrates the MAX77857 in a FC2QFN package, a
high-efficiency, high-performance buck-boost regulator
with a switching current of 7A. The IC is capable of 2.5V to
16V input and dynamically adjustable output between 4.5V
to 15V when using internal feedback resistors, or between
3V to 15V when using external feedback resistors. The EV
kit is factory-configured as internal feedback with default
startup output voltage at 5V. Other startup voltages can be
achieved with external feedback resistors. The output
voltage can be adjusted dynamically through the I
interface.
I/O pins are available to support the I
Enable function, and interrupt/Power-OK indicator. The
2
I
C slave address, switching current limit, and feedback
configuration can be adjusted by changing the R
resistor value (R9). MAXUSB_INTERFACE# allows the
®
use of Windows
-based software with a friendly graphical
user interface (GUI) as well as a detailed register-based
interface to exercise all features of the IC. The EV kit is
compatible with any version of the MAX77857 FC2QFN IC
(MAX77857BEFE+T is the default installed on the EV kit).
Check List
MAX77857Q IC Evaluation Board
MAXUSB_INTERFACE# (USB to I
USB Type-A to Micro-USB Cable
Windows-based Graphical User Interface (GUI) Software
• Can be downloaded from Maxim's website at
(under the Design Resources tab). Windows 7 or newer is required to use the EV kit GUI software.
EV Kit Specifications
SPECIFICATION
Input voltage
Output voltage
Default output voltage
Switching current limit
Peak efficiency
Windows is a registered trademark and registered service mark of Microsoft Corporation.
© 2022 Analog Devices, Inc. All rights reserved. Trademarks and registered trademarks are the property of their respective owners.
O n e A n al og W ay, W il mi ngton , MA 01887 U.S.A. | T el: 781. 329. 4700 | © 20 22 Analog Devic es, I nc. Al l ri ghts res erv ed.
2
C serial
2
C serial interface,
SEL
2
C Serial Interface)
https://www.maximintegrated.com/products/MAX77857QEVKIT
TEST CONDITION
Internal feedback
External feedback
Internal feedback
V
= 4V, V
= 5V, 700mA load
IN
OUT
MAX77857Q Evaluation Kit
Features
Proven PCB Reference Design and Layout Benefit
Fully Assembled and Tested
Sense Points for High-Accuracy Measurements
Accessible Test Point Pins for EN, POKB/INTB, V
2
and I
C Serial Interface SCL, SDA
MAXUSB_INTERFACE# Allows Easy Communication
with a Windows PC
GUI Software that Drives I
Optional Software Control
Startup Output Voltage Adjustable Through External
Feedback Resistors
Output Voltage Dynamically Adjustable Through I
Serial Interface
2
I
C Slave Address, Switching Current Limit, and
Feedback Configuration Adjustable Using R
Ordering Information
MIN
2.5
4.5
3
2
C Serial Interface for
SEL
appears at end of data sheet.
TYP
MAX
UNIT
16
15
15
5
7
97.0
319-100952; Rev 0; 9/22
,
IO
2
C
(R9)
V
V
V
A
%

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAX77857Q and is the answer not in the manual?

Questions and answers

Summary of Contents for Analog Devices MAX77857Q

  • Page 1 319-100952; Rev 0; 9/22 © 2022 Analog Devices, Inc. All rights reserved. Trademarks and registered trademarks are the property of their respective owners. O n e A n al og W ay, W il mi ngton , MA 01887 U.S.A. | T el: 781. 329. 4700 | © 20 22 Analog Devic es, I nc. Al l ri ghts res erv ed.
  • Page 2 Figure 1. MAX77857 Typical Application Circuit SWITCH NODES PROBE POINTS INPUT SUPPLY TERMINALS OUTPUT LOAD TERMINALS INPUT VOLTAGE SENSE PINS OUTPUT VOLTAGE SENSE PINS C SERIAL BUS TEST POINTS MAX77857 SOLUTION MAXUSB_INTERFACE# CONNECTOR Figure 2. MAX77857Q Evaluation Board www.analog.com Analog Devices | 2...
  • Page 3: Quick Start

    C serial interface (optional) • USB Type-A to Micro-USB cable (optional) • Windows-based PC with MAX77857 EV kit GUI (optional) Setup Overview Typical bench setups for the MAX77857Q EV kit with different configurations are shown in Figure Figure 4, and Figure www.analog.com...
  • Page 4 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit PGND1 PGND2 DC POWER ELECTRONIC SUPPLY LOAD MAX77857Q EV KIT PGND1S PGND2S DIGITAL DIGITAL VOLTMETER VOLTMETER OUTS J1: INSTALLED 1-2 J2: INSTALLED Figure 3. EV Kit Connection Block Diagram—Standalone Operation PGND1 PGND2 DC POWER...
  • Page 5: Standalone Operation

    This is useful for systems without a host controller or if the MAX77857 is the only power supply in the system. To configure the MAX77857Q EV kit for standalone operation, install header jumper J1 to position 1-2. This connects EN to V through a 510kΩ...
  • Page 6: Selection Table

    Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit header jumper J2. This connects V to V so that V is powered from V , eliminating the need for an external V power supply. MAXUSB_INTERFACE# The MAXUSB_INTERFACE# along with the companion EV kit GUI software allows users to easily change the MAX77857’s register settings with a Windows PC.
  • Page 7 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit Output Voltage Configuration By default, the EV kit is configured to use internal feedback resistors, with a 5V default startup output voltage and an output voltage range from 4.5V to 15V. To achieve a different default startup output voltage other than 5V, or to achieve a lower minimum output voltage range down to 3V, external feedback resistors are required.
  • Page 8 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit Critical Node Measurement (OUT and LX) The EV kit comes with probe points for measuring critical nodes OUT1, LX1, and LX2. See Figure 2 for their locations on the EV kit. Use these probe points to eliminate as much noise as possible when measuring the critical nodes. To ensure...
  • Page 9: Installation

    Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit Figure 7. MAX77857Q EV Kit GUI Software Configuration Tab Installation Visit the product webpage at https://www.maximintegrated.com/products/MAX77857QEVKIT and navigate to Design Resources to download the latest version of the EV kit software. Save the EV kit software installation file to a temporary folder and decompress the ZIP file.
  • Page 10 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit Figure 8. Port Synchronization Menu Figure 9. Device Synchronization Menu Configuration The Configuration tab (Figure 7) displays information and status of the IC on the EV Kit as well as all available register settings. It is divided into different sections: POK Status and Fault Interrupts, Output Voltage Configuration, and Miscellaneous Configuration.
  • Page 11 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit The POK Status and Fault Interrupt Masks section (Figure 11) configures the reflection of the bits in INT_SRC to the POKB/INTB pin. If a bit is masked, its status in the INT_SRC register is not shown on the POKB/INTB pin. Refer to the Power-OK Monitor and Fault Interrupts section in the IC data sheet for more information about the operation of the POKB/INTB pin.
  • Page 12 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit Figure 13. Configuration Tab—Miscellaneous Configuration Sections Register Map The Register Map tab provides an overview of all the MAX77857 registers and the values currently stored on them. Clicking on an individual bit shows the name and description of the specific bitfield.
  • Page 13 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit • Place the input capacitors (C ) and output capacitors (C ) immediately next to the IN pin and OUT pin of the IC, respectively. Since the IC operates at a high switching frequency, this placement is critical for minimizing parasitic inductance within the input and output current loops, which can cause high voltage spikes and can damage the internal switching MOSFETs.
  • Page 14: Ordering Information

    Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit Ordering Information DEFAULT OUTPUT PART U1 IC TYPE VOLTAGE MAX77857QEVKIT# MAX77857BEFE+T EV Kit #Denotes RoHS-compliant device that may include lead that is exempt under the RoHS requirements. +Denotes a lead(Pb)-free/RoHS-compliant package. www.analog.com Analog Devices | 14...
  • Page 15 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit MAX77857Q EV Kit Bill of Materials PART MFG PART # MANUFACTURER VALUE DESCRIPTION CAP; SMT (0402); 0.47UF; 10%; 6.3V; JMK105B7474KVHF TAIYO YUDEN 0.47UF X7R; CERAMIC CAP; SMT (0805); 10UF; 10%; 25V; C4, C5 GRM21BC71E106KE11...
  • Page 16 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit BRONZE WIRE SILVER PLATE FINISH; TSW- CONNECTOR; THROUGH HOLE; TSW-103-07-T-S SAMTEC 103-07- TSW SERIES; SINGLE ROW; STRAIGHT; 3PINS SULLINS CONNECTOR; MALE; THROUGH PBC02 PBC02SAAN ELECTRONICS HOLE; BREAKAWAY; STRAIGHT; SAAN CORP. 2PINS SULLINS PPPC0 CONNECTOR; FEMALE; THROUGH...
  • Page 17 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit MAX77857Q EV Kit Schematic www.analog.com Analog Devices | 17...
  • Page 18 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit MAX77857Q EV Kit PCB Layouts MAX77857Q EV Kit Component Placement Guide—Top MAX77857Q EV Kit PCB Layout—Internal 2 Silkscreen MAX77857Q EV Kit PCB Layout—Top View MAX77857Q EV Kit PCB Layout—Internal 3 www.analog.com Analog Devices | 18...
  • Page 19 Evaluates: MAX77857 (FC2QFN) MAX77857Q Evaluation Kit MAX77857Q EV Kit PCB Layouts (continued) MAX77857Q EV Kit PCB Layout—Internal 4 MAX77857Q EV Kit PCB Layout— Bottom View MAX77857Q EV Kit PCB Layout—Internal 5 www.analog.com Analog Devices | 19...
  • Page 20: Revision History

    Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
