(TXCLKOUT+)-(TXCLKOUT-)
(TXOUT_+)-(TXOUT_-)
GMSL2 oLDI deserializers can be configured as single port (4 or 8 lanes) or dual port (2x4 lanes) to accommodate a
range of display applications. Each port supports pixel clock (PCLK) rates up to 150MHz and a combined PCLK of
300MHz in Dual-port mode. Video data can be mapped to oLDI ports A, B, or both. Additionally, video lanes can be
inverted and/or swapped to assist in compatibility with display interfaces. Both oLDI and VESA output formats are
supported.

LVDS Data Mapping

The following sections provide the LVDS data mapping for single- and dual-port oLDI output.

Single Pixel per Clock Output

TxOUT0 G2
TxOUT1 B3
TxOUT2 DE
TxOUT3 XX
www.analog.com
tPPOS0
tPPOS1
tPPOS2
tPPOS3
tPPOS4
tPPOS5
tPPOS6
Figure 7. LVDS pulse positions
R7 R6
B2 G7
VS HS
B1 B0
Figure 8. Single oLDI Port Mapping (oLDI/Format 1)
CLK
R5 R4
G6 G5
B7 B6
G1 G0
R3 R2
G4 G3
B5 B4
R1 R0
