Analog Devices MAX32690FTHR User Manual

Evaluates: MAX32690
General Description
The MAX32690FTHR board is a rapid development
platform to help engineers quickly implement battery
optimized Bluetooth® 5.2 Low Energy (LE) solutions with
the MAX32690 Arm® Cortex®-M4 processor.
The form factor is a small 0.9-inch by 2.47-inch dual-row
header footprint compatible with Adafruit Feather Wing
peripheral expansion boards.
The board features the MAX77654 PMIC for efficient
battery and power management, a CAN transceiver with a
dedicated interface connector, an RGB indicator LED, and
two user pushbuttons.
MAX32690FTHR EV Kit Contents
•
MAX32690FTHR Board
•
MAX32625PICO Debugger with Cables
•
Feather Form Factor Compatible 12-pin and 16-pin
Male Headers
•
USB Micro-B Cable
•
Insert Card
Add Doc ID to DOC_ID variable
O n e A n a l o g W a y , W i l m i n g t o n , M A 0 1 8 8 7 - 2 3 5 6 , U . S . A .
Evaluation Board User Guide
Features
•
MAX32690 Arm® Cortex® -M4F with FPU up to
120MHz
•
3.25MB Flash Memory
•
1MB SRAM
•
Bluetooth 5.2 LE with Integrated PCB Antenna
•
High-Speed USB 2.0
•
QSPI, UART, CAN 2.0B, I
Interfaces
•
12-bit ADC
•
PMIC
•
RGB Indicator LED
•
2 General-purpose Pushbutttons
Ordering Information
PART
MAX32690FTHR#
DOCUMENT FEEDBACK
T e l : 7 8 1 . 3 2 9 . 4 7 0 0 © 2 0 2 4 A n a l o g D e v i c e s , I n c . A l l r i g h t s r e s e r v e d .
MAX32690FTHR
2 C, I2S, 1-Wire Master®
TYPE
Evaluation Board
TECHNICAL SUPPORT
