• 3.5 mm stereo headphones
• 6-foot RCA audio cable
• 6-foot 3.5 mm/RCA x 2 Y-cable
If any item is missing, contact the vendor where you purchased your
EZ-KIT Lite or contact Analog Devices, Inc.

Default Configuration

The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent
damage may occur on devices subjected to high-energy discharges. Proper
ESD precautions are recommended to avoid performance degradation or
loss of functionality. Store unused EZ-KIT Lite boards in the protective
shipping package.
The ADSP-21375 EZ-KIT Lite board is designed to run outside your per-
sonal computer as a standalone unit. You do not have to open your
computer case.
When removing the EZ-KIT Lite board from the package, handle the
board carefully to avoid the discharge of static electricity, which may dam-
age some components.
switch, connector locations, and LEDs used in installation. Confirm that
your board is set up in the default configuration before continuing.
ADSP-21375 EZ-KIT Lite Evaluation System Manual
Using the ADSP-21375 EZ-KIT Lite
Figure 1-1 shows the default jumper settings, DIP
1-3
