The beginning of the register address space for each LUT corresponds to the LSB of the respective color.
The LUT can be reverted to a 1:1 straight color mapping after the random value assignment at power-up. For
example, use the following programming pattern to revert the red color LUT of the oLDI deserializer to 1:1 mapping
values:
• 0x1000 = 0x00
• 0x1001 = 0x01
• 0x1002 = 0x02
• ...
• 0x10FF = 0xFF
Enable the LUT using the LUT_x_EN register bit after programming the LUT registers.
The tables below contain the LUT register information. These include the address range for each LUT and their
corresponding enable bits. After configuring, the incoming pixel data will automatically translate to the new
output LUT values after enabling the LUT enable bit.
Note: LUTs cannot be partially enabled. If color translation is needed, all three LUTs must be enabled. See
LUTs for more information.

oLDI Deserializers

Table 3. oLDI Deserializer LUT Registers
Field / Register Address Range /
Name Register Name
LUT_A (RED) 0x1000 – 0x10FF
register space
LUT_B (GREEN) 0x1100 – 0x11FF
register space
LUT_C (BLUE) 0x1200 – 0x12FF
register space
LUT_A_EN 0x01CD / OLDI0
LUT_B_EN 0x01CD / OLDI0
LUT_C_EN 0x01CD / OLDI0

Readback Restriction

The following sequence is common in typical use cases:
• Program the LUT translation values.
• Readback the LUT translation values (to ensure proper programming).
• Enable the LUT.
www.analog.com
Bit Position
0
1
2
Default Value
Random
Random
Random
0: Disabled
0: Disabled
0: Disabled
Enabling
Description
Address Range for
RED LUT Data
Address Range for
GREEN LUT Data
Address Range for
BLUE LUT Data
Enables LUT_A
(RED) translation
Enables LUT_B
(GREEN) translation
Enables LUT_C
(BLUE) translation
