Dosimag IO-Link
Signal on alarm
Endress+Hauser
Assignable measured
variables
Switch output
Switching behavior
Number of switching
cycles
Assignable functions
IO-Link
Physical interface
Signal
IO-Link version
IO-Link SSP version
IO-Link device port
The pin assignment deviates from the IO-Link standard to enable compatibility with
previous device versions and installations.
Depending on the interface, failure information is displayed as follows.
Pulse/frequency/switch output
Pulse output
Failure mode
Frequency output
Failure mode
Switch output
Failure mode
IO-Link
Operating mode
Device status
• Volume flow
• Temperature
Binary, conductive or non-conductive
Unlimited
• Off
• On
• Diagnostic behavior
• Alarm
• Alarm and warning
• Warning
• Limit value:
• Off
• Volume flow
• Flow velocity
• Status
Low flow cut off
According to Standard IEC 61131-9
IO-Link digital communication signal, 3-wire
1.1
Identification and Diagnosis, Measuring and Switching Sensor (as per SSP 4.3.4)
IO-Link port class A
Choose from:
• Actual value
• No pulses
Choose from:
• Actual value
• 0 Hz
• Definable value between: 0 to 10 000 Hz
Choose from:
• Current status
• Open
• Closed
Digital transmission of all failure information
Readable via cyclical and acyclical data transmission
Technical data
