About this document
6
Symbol Meaning
Tip
Indicates additional information.
Reference to documentation
Reference to page
A
Reference to graphic
Notice or individual step to be observed
, , ... Series of steps
1. 2. 3.
Result of a step
Help in the event of a problem
Visual inspection
1.2.4

Symbols in graphics

Symbol Meaning
1, 2, 3, ... Item numbers
, , , ... Series of steps
1. 2. 3.
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
Hazardous area
-
Safe area (non-hazardous area)
.
Flow direction
1.3

Documentation

For an overview of the scope of the associated Technical Documentation, refer to the
following:
• Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the
nameplate
• Endress+Hauser Operations app: Enter serial number from nameplate or scan
matrix code on nameplate.
The following documentation may be available depending on the device version ordered:
Document type
Technical Information (TI)
Brief Operating Instructions (KA)
Purpose and content of the document
Planning aid for your device
The document contains all the technical data on the device and provides
an overview of the accessories and other products that can be ordered for
the device.
Guide that takes you quickly to the 1st measured value
The Brief Operating Instructions contain all the essential information
from incoming acceptance to initial commissioning.
