Technical data

16.1

Application

To ensure that the device remains in proper operating condition for its service life, use the
measuring device only for media against which the process-wetted materials are
sufficiently resistant.
16.2

Function and system design

Electromagnetic flow measurement on the basis of Faraday' s law of magnetic induction.
Compact version – transmitter and sensor form a mechanical unit in a fully welded
housing.
For information on the structure of the measuring instrument →  10
16.3

Input

Direct measured variables
• Volume flow (proportional to induced voltage)
2)
• Temperature
Typically v = 0.01 to 10 m/s (0.03 to 33 ft/s) with the specified measurement accuracy
Flow characteristic values in SI units
Nominal diameter
[mm]
4
8
1)
15K
15
25
1) Conical version (corresponds to DN 12)
Recommended
Flow rate
Maximum full scale value
[l/s]
0.14
0.5
1.2
1.66
5
Technical data
Factory settings
Low flow cut off
Pulse value
(v ~ 0.04 m/s)
[ml] [ml/s]
0.005 0.5
0.02 2
0.1 7
0.1 7
0.2 16
