Dosimag IO-Link
Storage temperature
Degree of protection
Vibration-resistance and
shock-resistance
Internal cleaning
Electromagnetic
compatibility (EMC)
Medium temperature range
Endress+Hauser
Temperature tables
Observe the interdependencies between the permitted ambient and fluid
temperatures when operating the device in hazardous areas.
For detailed information on the temperature tables, see the separate document
entitled "Safety Instructions" (XA) for the device.
The storage temperature corresponds to the ambient temperature range →  19.
• Protect the measuring instrument against direct sunlight during storage in order to
avoid unacceptably high surface temperatures.
• Select a storage location where moisture cannot collect in the measuring instrument as
fungus or bacteria infestation can damage the liner.
• If protective caps or protective covers are mounted, only remove them immediately
before mounting the measuring instrument.
Standard: IP67, Type 4X enclosure, suitable for pollution degree 4
Vibration sinusoidal, in accordance with IEC 60068-2-6
• 2 to 8.4 Hz, 7.5 mm peak
• 8.4 to 2 000 Hz, 2 g peak
Vibration broad-band random, according to IEC 60068-2-64
2
• 10 to 200 Hz, 0.01 g /Hz
• 200 to 2 000 Hz, 0.003 g
• Total: 2.70 g rms
Shock half-sine, according to IEC 60068-2-27
6 ms 50 g
Rough handling shocks according to IEC 60068-2-31
• CIP cleaning
• SIP cleaning
Observe the maximum medium temperatures →  59
As per IEC/EN 61326
Details are provided in the Declaration of Conformity.
This unit is not intended for use in residential environments and cannot guarantee
adequate protection of the radio reception in such environments.
16.9

Process

Measuring instrument
–20 to +130 °C (–4 to +266 °F)
Cleaning
Process connections with aseptic molded seal and Tri-Clamp: +150 °C (+302 °F) max.
60 min for CIP and SIP processes
2 /Hz
Technical data
59
