Technical data
Low flow cut off
Galvanic isolation
Protocol-specific data
56
The switch points for low flow cut off are user-selectable.
Device version: IO-Link, 1 pulse/frequency/switch output
(Order code for "Output, input": option FA)
Pulse/frequency/switch outputs on supply potential.
IO-Link
IO-Link specification
Device ID
Manufacturer ID
Smart Sensor Profile 2nd
Edition
Smart Sensor Profile Type
SIO
IO-Link transmission rate
Minimum period
Process data width input/
output
OnRequestdata PreOp/Op
Data storage
Block configuration
Device operational
System integration
Device description
In order to integrate field devices into a digital communication system, the IO-Link system
needs a description of the device parameters, such as output data, input data, data format,
data volume and supported transmission rate.
The data are included in the device description (IODD) that are provided to the IO-Link
master during commissioning of the communication system.
The IODD can be downloaded as follows:
• www.endress.com
• https://ioddfinder.io-link.com
Version 1.1.3
0x947501 (9729281)
0x0011 (17)
Supports
• Identification and Diagnosis
• Digital Measuring and Switching Sensor (as per SSP type 4.3.4)
Measuring profile type 4.3.4 Measuring and Switching Sensor, floating point,
4 channel
Yes
COM3; 230.4 kBd
1.5 ms
18 bytes/2 bytes (as per SSP 4.3.4)
8 bytes/2 bytes
Yes
Yes
The device is operational 3 seconds after the supply voltage is applied
Input cyclic process data
• Volume flow [m³/h]
• Totalizer 1 [m³]
• Temperature [°C], depending on the sensor option selected
Output cyclic process data
• Control signal channel - Volume flow
• Control signal channel - Temperature
• Control signal channel - Totalizer 1
• Flow override
• Totalizer 1 - Hold
• Totalizer 1 - Reset + totalize
• Totalizer 1 - Reset + hold
• Totalizer 1 - Totalize
