Dosimag IO-Link
Surface roughness
Languages
Local operation
IO-Link
Endress+Hauser
Tri-Clamp
• Tri-Clamp (ASME BPE)
• ³⁄₄" Tri-Clamp L14 AM7
• 1" Tri-Clamp L14 AM7
With O-ring seal
Gland
G1" external thread (EN ISO 228/EN 10226)
Process connection materials →  62
Data relate to surfaces in contact with the medium.
Stainless steel electrodes, 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022), platinum,
tantalum:
≤ 0.3 to 0.5 µm (11.8 to 19.7 µin)
Liner with PFA:
≤ 0.4 µm (15.7 µin)
Stainless steel process connections:
• With O-ring seal: Ra ≤ 1.6 µm (63 µin)
• With aseptic molded seal: R

16.11 Operability

Can be operated in the following languages:
Via "FieldCare", "DeviceCare" operating tool: English, German, French, Spanish, Italian,
Chinese, Japanese
This device cannot be operated locally using a display or operating elements.
The device-specific parameters are configured via IO-Link. There are specific
configuration or operating programs from different manufacturers available to the
user for this purpose. The device description file (IODD) is provided for the device.
IO-Link operating concept
Operator-oriented menu structure for user-specific tasks. Efficient diagnostic behavior
increases measurement availability:
• Diagnostic messages
• Remedial measures
• Simulation options
IODD download
Two options to download the IODD:
• www.endress.com/download
• https://ioddfinder.io-link.com/
www.endress.com/download
1. Select "Device drivers".
2. Select the "IO Device Description (IODD)" entry under "Type".
3. Select "Product root".
4. Click "Search".
 A list of search results is displayed.
= 0.76 µm (30 µin)
amax
Technical data
