Dosimag IO-Link
Parameter
Serial number
Order code
Firmware version
Extended order code 1
Extended order code 2
Extended order code 3
ENP version
Manufacturer
Endress+Hauser
Description
Displays the serial number of the measuring device. The serial
number is also provided on the nameplate of the sensor and of
the transmitter.
The serial number can also be used to retrieve further device-
related information and documentation via the Operations app
or the Device Viewer on the Endress+Hauser website.
Displays the device order code.
The order code is used for instance to order a replacement or
spare device or to verify that the device features specified on the
order form match the shipping note.
Displays the device firmware version installed.
Displays the first, second and/or third part of the extended
order code.
Due to character length restrictions, the extended order code is
split into a maximum of 3 parameters. The extended order code
indicates for each feature in the product structure the selected
option, thereby uniquely identifying the device model.
The extended order code can also be found on the nameplate.
Displays the first, second and/or third part of the extended
order code.
Due to character length restrictions, the extended order code is
split into a maximum of 3 parameters. The extended order code
indicates for each feature in the product structure the selected
option, thereby uniquely identifying the device model.
The extended order code can also be found on the nameplate.
Displays the first, second and/or third part of the extended
order code.
Due to character length restrictions, the extended order code is
split into a maximum of 3 parameters. The extended order code
indicates for each feature in the product structure the selected
option, thereby uniquely identifying the device model.
The extended order code can also be found on the nameplate.
Displays the version of the electronic nameplate (ENP).
Displays the manufacturer.
Diagnostics and troubleshooting
User interface / User entry
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
Character string comprising numbers, letters
and special characters
