Appendix A Specifications
DSAM-1500, -2500. -2600, -3500, 3600, 6000 Specifications
Table 2 Product Specifications (Continued)
Item
Weight (Models 1500, 2500, and
3500)
Weight (Model 2600 and 3600)
Storage and Operating Tempera-
ture Range
DSAM-3500 and - 3600 Additional Specifications
Downstream Spectrum
(forward scan)
Frequency range
Sweep rate
Display scaling and range
Resolution bandwidth
Span
a
Sensitivity
Constellation (optional)
Modulation type
Constellation points
Zoom
Cable modem diagnostic page
f
IP address
a. Typical integrated power, detectable range.
52
Description
2 pounds, 12 ounces (1.3kg)
3 pounds, 4 ounces (1.5kg)
-20 to +50°C; (0 to +120°F)
40 to 1000 MHz
Less than 2.5 seconds
5 and 10 dB/division; 6 vertical
divisions
300 kHz
10 MHz or 50 MHz
-35 to 60 dBmV (typical)
64 and 256 QAM
2000, 4000, 8000, 16000, 32000,
or 64000
up to 4 levels
192.168.100.1
