Contrast Adjustment (Extreme Temperature Change)

DSAM Product Family Quick-Start Guide Rev. G

Contrast Adjustment (Extreme Temperature Change)

Your DSAM provides two modes of contrast adjustment
(AUTO and MANUAL). The AUTO mode provides a
limited contrast adjustment based upon the sensed
temperature range. The MANUAL mode provides a full
contrast adjustment across the entire operational temper-
ature range (0 to +120 degrees Fahrenheit or -20 to +50
degrees Celsius).
To adjust the contrast
1 To quickly access the ADJUST CONTRAST configu-
ration screen, press
2 To switch between contrast modes (AUTO or
MANUAL), press the
NOTE:
– When an extreme change in temperature is
encountered the MANUAL mode is highly
recommended.
– When AUTO is displayed the DSAM is in the
MANUAL mode and vice versa.
– The factory default mode is AUTO.
3 Adjust the degree of difference between the lightest
and darkest areas of the screen by using the right and
left arrow keys to move the contrast indicator (slider)
on the ADJUST CONTRAST configuration screen.
NOTE:
To perform a repetitive contrast adjustment, press and
hold the right or left arrow key. The factory default for
screen contrast is 50%.
Chapter 2 DSAM Operation
SHIFT 7.
softkey farthest to the right.
45
