Chapter 2 DSAM Operation
Powering the Meter
Interpreting
the "Charge"
LED
14
mode, the battery temperature should be approximately
between 32 °F (0 °C) and 122 °F (50 °C). Fast charge
mode automatically resumes when the battery tempera-
ture returns within this range.
There are two LED indicator lights on your DSAM charger
module -- the "Power" LED and the "Charge" LED.
The green "Power" LED illuminates to indicate that the
charger module is receiving power.
The "Charge" LED illuminates in red, green, or orange to
indicate the present battery and charge condition. It may
remain on constantly, or it may begin to flash. To interpret
the "Charge" LED indications, review
Table 1 Charge LED indications
LED LED
color activity
Red On
(constant)
Green On
(constant)
Red Flashing
Orange Flashing
DSAM Product Family Quick-Start Guide Rev. G
Table 1.
Battery and charge
condition
Charger module is in fast
charge mode; maximum
charge is delivered to bat-
tery
Fast charge cycle is com-
plete; battery is ready for
use and in maintenance
charge mode while
attached to the charger
module
Battery-related error or
defect detected; min/max
cell voltage or battery tem-
perature is out of range)
DC input voltage is out of
range.
