Fan Cabling - HPE ProLiant MicroServer Gen10 Plus v2 User Manual

Hide thumbs Also See for ProLiant MicroServer Gen10 Plus v2:
Table of Contents

Advertisement

Color
Color
Description
Description
Orange Drive power cable
Blue
Drive sideband signal cable
Gold
Drive data cable
Pink
Ambient temperature sensor cable

Fan cabling

Fan cabling
HPE ProLiant MicroServer Gen10 Plus v2 User Guide
65
