Introduction

The UHD Multicast distribution platform allows distribution of HDMI video over a 1Gb Network switch. The ACM200 &
ACM210 Advanced Control Modules (known as 'ACM' from this point forwards in this guide) allow advanced third party
control of the Multicast system using TCP / IP, RS-232 and IR.
The ACM includes a web interface module for control and configuration of the Multicast system and features 'Drag &
Drop' source selection with media preview and independent routing of Video, Audio, IR, RS-232, and USB / KVM.
Pre-built Blustream product drivers simplify Multicast product installation and negate the need for an understanding
of complex network infrastructures.
This User Guide covers the features and functionality for both the ACM200 and ACM210 Advanced Control Module
products from Blustream.
The ACM200 is currently used for IP50HD, IP200UHD and IP250UHD systems only.
The ACM210 can be used for individual IP50HD, IP200UHD, IP250UHD, IP300UHD and IP350UHD systems.
Please note: IP200UHD and IP250UHD systems are interoperable. IP300UHD and IP350UHD systems are interoperable.
The IP50HD is a standalone system and is not interoperabel with eithe rof the above 2 sets of Multciast systems.
Features
• Web interface module for configuration and control of the Blustream Multicast system
• Intuitive 'Drag & Drop' source selection with video preview feature for active monitoring of system status
• Advanced signal management for independent routing of Video, Audio, IR, RS-232, and USB/KVM
• Auto system configuration
• 2x RJ45 LAN connections to bridge existing network to Multicast video distribution network, resulting in:
- Better system performance as network traffic is separated
- No advanced network setup required
- Independent IP address per LAN connection
- Allows simplified TCP/IP control of Multicast system
• RS-232 integration for control of Multicast system
• IR integration for control of Multicast system
• PoE (Power over Ethernet) to power ACM from PoE switch
• Local 12V power supply (optional) should switch not support PoE
• Support for iOS and Android App control
• 3rd party drivers available for most control brands
Impotant Note:
The Blustream Multicast system distributes HDMI video over managed network hardware. It is advised that Blustream
Multicast products are connected on an independent network switch (or VLAN) to prevent unnecessary interference, or
reduction in signal performance due to other network products bandwidth requirements.
Please read and understand the instructions in this manual and ensure that the network switch is configured correctly
prior to connecting any Blustream Multicast products. Failure to do so will result in problems with configuration of the
system and video performance.
