Status feedback samples
Command: IN xxx STATUS
An overview of the input (Transmitter: xxx). Including: firmware, audio, name etc.
================================================================
IP Control Box ACM200 Input Info
FW Version: 1.14
In Net Sig Ver EDID Aud
001 On On A7.3.0 DF015 HDMI On
CEC LED SGEn/Br/Bit
On 3 Off /9/8n1
IM MAC
Static 00:19:FA:00:58:23
IP GW
169.254.003.001 169.254.003.001 255.255.000.000
================================================================
Command: VW STATUS
The VW STATUS will show all VW status feedback for Video Wall arrays in the system. Additional Video Wall arrays will have
individual status feedback i.e. 'VW 2 STATUS'.
================================================================
IP Control Box ACM200 Video Wall Info
FW Version: 1.14
VW Col Row CfgSel Name
02 02 02 02 Video Wall 2
OutID
001 002 003 004
CFG Name
01 Configuration 1
Group FromIn Screen
A 004 H01V01 H02V01 H01V02 H02V02
02 Configuration 2
Group FromIn Screen
A 002 H02V01 H02V02
B 001 H01V01 H01V02
================================================================
45
MCast Name
Transmitter 001
SM
