Web-GUI - Settings - continued...
The 'Reset ACMxxx' option allows for the following:
1. Reset System to factory default (excludes Network settings)
2. Reset Network to default settings (excludes System settings)
3. Reset ALL System and Network settings back to factory default
Under general settings, the 'Update' option allows for the following:
1. Turn On / Off IR control to enable / disable the IR input of the ACM from accepting IR commands from a third party
control solution.
2. Update the Telnet port number that the Control port of the ACM communicates through. The default port number
used is port 23 which will be used for all official Blustream third party control drivers.
3. Update the RS-232 Baud Rate of the DB9 connection of the ACM to suit a third party control processor. The default
Baud Rate used is: 57600.
The IP addresses of the two RJ45 ports on the ACM can be updated with individual IP, Subnet and Gateway addresses.
Use the 'Update' button for either the Control Network or Video Network to update the information for the ports
required. The Control Port can be set to DHCP by selecting 'On':
IMPORTANT: Amending the Video Network IP Address out of the 169.254.x.x range will stop communication between
the ACM and the Multicast Transmitters and Receivers that have been pre-configured. Whilst the ACM can be moved
out of the recommended range, the IP addresses of ALL Transmitters and Receivers would need to be amended to the
same IP range to ensure connectivity and control of the Multicast system. Not recommended.
