BluStream Multicast ACM200 User Manual page 42

Specifications
ACM200 & ACM210:
• Ethernet port: 2x LAN RJ45 connector (1x PoE support)
• RS-232 serial port: 1x DB-9 female
• RS-232 & I/O port: 1x 6-pin Phoenix connector (reserved for future use)
• IR input port: 1x 3.5mm stereo jack
• Dimensions (W x D x H
• Shipping weight (Kit): 0.6kg
• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
Package Contents
• 1 x ACM200 / ACM210
• 1 x IR control cable - 3.5mm to 3.5mm stereo to mono cable
• 1 x 6-pin phoenix connector
• 1 x Mounting kit
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
contact support@blustream.co.uk / support@blustream.com.au / support@blustream-us.com
): 96mm x 110mm x 26mm
ACM - Multicast Advanced Control Module USER MANUAL
42
