BluStream Multicast ACM200 User Manual page 27

Fixed Routed USB / KVM
The fixed USB routing feature allows a fixed USB link between a Multicast Receiver/s and a Transmitter. This can be
useful for sending KVM signals between a users position to a centrally located PC, server, CCTV DVR / NVR etc.
Rx Tx Gnd
CH SELECT
CH
RS-232 UPDATE
MULTICAST UHD
HDMI IN
AUDIO
IR IR
DC IN
LAN / PoE
IN OUT
24~56V
PC, server, CCTV NVR / DVR etc
USB Specifications:
USB Specification
Extension
Distance
Distance Ext.
Max Downstream Devices
Topology
USB R/W Performance *
Fixed Routed CEC
CEC or Consumer Electronic Command is a HDMI embedded control protocol that allows for commands to be sent
from one HDMI device to another for simple actions such as: Power, Volume etc.
The Blustream Multicast system allows for the CEC channel within the HDMI link between two products (source and
sink) to communicate with eachother using the CEC protocol.
CEC must be enabled (this is sometimes referred to as 'HDMI Control') on both the source device and the display
device in order for the Multicast system to communicate the CEC commands over the Multicast link.
Please note: the Blustream Multicast system will only transport the CEC protocol transparently. It is advisable to
ensure that the source and sink devices will communicate effectively before committing to this control type with
Multicast. Should an issue be experienced with CEC communication between the source and sink directly, this will be
mirrored when sending through the Multicast system.
contact support@blustream.co.uk / support@blustream.com.au / support@blustream-us.com
IR IR
LINK
USB
CH SELECT
IP200UHD-TX
OUT IN
1 USB 2
USB
L / R
IN
LAN / PoE LOOP OUT
USB2.0 (please note: does not support full USB2.0 data transfer rates)
Over IP, Hybrid redirection technology
100m
via Ethernet switch hub
5
1 to 1
1 to many exclusively (USBoIP)
1 to many simultaneously but limited number of USB devices (USBoIP)*
1 to many simultaneously Keyboard / Mouse (K/MoIP)
R: 69.6 Mbps
W: 62.4 Mbps
* Benchmark Reference: Read / Write USB to SATA HD without Multicast system R: 161.6 Mbps / W: 161.6 Mbps
ACM - Multicast Advanced Control Module
Rx Tx Gnd
Rx Tx Gnd
LINK
CH SELECT
CH
RS-232 UPDATE
CH RS-232 MULTICAST UHD UPDATE
MULTICAST UHD
IP200UHD-RX
HDMI IN
HDMI OUT
AUDIO
IR IR
DC IN
DC IN
LAN / PoE L / R IN
IN OUT
24~56V
24~56V
IR IR
LINK
USB
CH SELECT CH
IP200UHD-TX
OUT IN
1 USB 2
HDMI OUT
USB
L / R
LAN / PoE LOOP OUT
Keyboard / mouse
USER MANUAL
Rx Tx Gnd
LINK
RS-232 UPDATE
MULTICAST UHD
IP200UHD-RX
DC IN
L / R
24~56V
