Status feedback samples
Command: STATUS
The STATUS feedback gives an overview of the network the ACM is connected to:
================================================================
IP Control Box ACM200 Status Info
FW Version: 1.14
Power IR Baud
On On 57600
In EDID IP NET/Sig
001 DF009 169.254.003.001 On /On
002 DF016 169.254.003.002 On /On
Out FromIn IP NET/HDMI Res Mode
001 001 169.254.006.001 On /Off 00 VW02
002 002 169.254.006.002 On /Off 00 VW02
LAN DHCP IP Gateway
01_POE Off 169.254.002.225 169.254.002.001 255.255.000.000
02_CTRL Off 010.000.000.225 010.000.000.001 255.255.000.000
Telnet LAN01 MAC LAN02 MAC
0023 34:D0:B8:20:4E:19
================================================================
Command: OUT xxx STATUS
The OUT xxx STATUS feedback gives an overview of the output (Receiver: xxx). Including: firmware, mode, fixed
routing, name etc.
================================================================
IP Control Box ACM200 Output Info
FW Version: 1.14
Out Net HPD Ver Mode Res Rotate Name
001 On Off A7.3.0 VW
Fast Fr Vid/Aud/IR_/Ser/USB/CEC
On 001 001/004/000/000/002/000
CEC DBG Stretch IR BTN LED SGEn/Br/Bit
On On Off On On
IM MAC
Static 00:19:FA:00:59:3F
IP GW SM
169.254.006.001 169.254.006.001 255.255.000.000
================================================================
contact support@blustream.co.uk / support@blustream.com.au / support@blustream-us.com
SubnetMask
34:D0:B8:20:4E:1A
00 0 Receiver 001
HDR MCas
On On
3 Off /9/8n1
