29.3
Electromagnetic Immunity
ESD, transient/burst, surge, voltage variation and magnetic Fields are described in
Electronic Immunity Test Levels are described in
Table 22
ESD, Transient/Burst, Surge, Voltage Variation, Magnetic Fields
Immunity Test
Electrostatic
discharge (ESD)
IEC 61000-4-2
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines IEC 61000-4-11
Power frequency
(50/60 Hz) magnetic
field IEC 61000-4-8
58
IEC 60601-1-2 Test
Level
± 8 kV
contact discharge
± 2, 4, 8, 15 kV
air discharge
±2 kV AC Mains
±1 kV I/O Lines
±0.5 kV, ±1 kV
Line to Line
±0.5 kV, ±1 kV, ±2 kV
Line to Ground
Voltage dips:
0% UT
(100% dip in UT) for 0.5
cycle at 0°, 45°, 90°,
135°, 180°, 225°, 270°,
315°
0% UT
(100% dip in UT) for 1
cycle at 0°
70% UT
(30% dip in UT) for 25
cycles at 0°
Voltage Interruptions:
0%
UT
(100% dip in UT) for 250
cycles
30 A/m
www.vareximaging.com
Azure 3131Z - 4131Z Reference Manual
Table 23 on page
Compliance
± 8 kV
contact discharge
± 2, 4, 8, 15 kV
air discharge
±2 kV AC Mains
±1 kV I/O Lines
±0.5 kV, ±1 kV
Line to Line
±0.5 kV, ±1 kV, ±2 kV
Line to Ground
Voltage dips:
0% UT
(100% dip in UT) for
0.5 cycle at 0°, 45°, 90°,
135°, 180°, 225°, 270°,
315°
0% UT
(100% dip in UT) for 1
cycle at 0°
70% UT
(30% dip in UT) for 25
cycles at 0°
Voltage Interruptions:
0%
UT
(100% dip in UT) for
250 cycles
30 A/m
Table
59.
Electromagnetic
Environment
Floors should be wood,
concrete, or ceramic tile. If
floors are covered with
synthetic material, the relative
humidity should be at least
30%.
Mains power quality should
be that of a typical commercial
or hospital environment.
Mains power quality should
be that of a typical commercial
or hospital environment.
Mains power quality should
be that of a typical commercial
or hospital environment. If the
user of the X-ray detector
requires continued operation
during power mains
interruptions, it is
recommended that the system
be powered from an
uninterruptible power supply
or a battery.
Magnetic field should be that
of a typical location in a
typical commercial or hospital
environment.
22.
