OEM/System Integrator User Interfaces

The following information is designed for those OEMs and system integrators that want to
develop their own user interfaces or embed functionality into their applications using the Varex
Imaging hardware connections and SDK APIs. This section is for advanced users of the Varex
Imaging X-ray detectors. If you have any questions please contact your Varex Imaging
representative for detailed assistance.
20.1

Generator Interface Signals

Hardware signals are used to interface between the X-ray detector and the User Generator
Interface. The detector's 9-Pin D-Sub External Sync connector, shown in
interface and its signals are listed in
Figure 7 9-Pin D-Sub External Sync Connector on the X-ray Detector
Table 17 Male External Sync 9-Pin D-Sub Pin-out
Connector Pin
1
2
3
4
5
6
7
8
9
28
Table 17.
Expose_OK
External_Sync Positive
External_Sync Negative
Disable Exp_OK Positive
Disable Exp_OK Negative
Detector_Ready
www.vareximaging.com
Azure 3131Z - 4131Z Reference Manual
Figure 7,
Signal
User_5V
User GND
User_5V
is used for the
