Device Class Filtering
3
drop-down list to select among USB 2.0, HID + CAC, and HID Only.
NOTE: USB Device Class filtering limits the functionality of the
USB port.
• USB 2.0 — No restrictions, allows all USB devices to
function.
• HID + CAC — Allows only devices such as a keyboard,
mouse, and a card reader (common access card) to
function.
• HID Only — Allows only devices such as a keyboard and
mouse to function.
Peripheral Emulation
4
mode, emulates a keyboard and mouse to the connected host computer, allowing
faster USB switching.
SAVE and CANCEL buttons
5
abandon them. Clicking either button closes the editable pane.
Networking page
On the Networking Settings page (see figure 57), click the down arrow (
drop-down menu (see Network Connection page
SFP Module Info on page 59).
Figure 57. Networking Settings Page
(see figure 56 on page 54) — Click the
— This feature, available only if the endpoint is set to Host
— Click SAVE to take USB changes or CANCEL to
on page 56,
NAV E 511 Encoder • HTML Operation
) to open a
1
Port page on page 58, or
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
55
