FIRMWARE tab
Upgrade the encoder firmware as follows:
NOTES:
• Firmware upgrade is disabled when the encoder is accessed via proxy from the
NAVigator.
• Upgrading the encoder firmware results in the unit rebooting.
• Valid firmware files have the .eff file extension. Any other file extension is not a valid
firmware update.
1. On the Device Tools page, click FIRMWARE (see figure 32,
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Figure 32. Tools — Firmware Function
2. ). An Open dialog box opens (see figure 33).
Click SELECT FILE (
2
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Figure 33. Open Dialog Box
3.
Navigate to the folder where you saved the firmware upgrade file (see figure 33,
Select the file.
). The Open dialog box closes and the Tools pane returns to the top,
4. Click Open (
2
with the selected firmware file identified (see
).
1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
figure 34, on page 40).
1
