Extron electronics NAV E 511 User Manual page 26

3. Press the keyboard <Enter> key.
NOTES:
• If you do not have the trusted SSL Certificate, the browser displays a
privacy notification (see figure 10). Continue to the login dialog box as follows:
1. Click the browser button that advances past the privacy notification (such as
Advanced [1] in Chrome). Explanatory text and a link appear.
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Figure 10.
2. Click Proceed to <IP address> (unsafe) (2) (or similar message).
• Your IT department can provide an uploadable SSL Certificate (see
page 65). Once the certificate is loaded, the notification does not occur.
The browser opens to the Login dialog box (see figure 11).
1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2
3 3 3 3 3 3 3 3 3 3 3 3 3 3
Figure 11. Login Dialog Box
4.
Enter the Username (1) and Password (2) and click Sign In (3). The browser opens
the embedded encoder web pages (see
NOTES:
• The factory configured passwords for all accounts on this device have been
set to the device serial number. In the event of a complete system reset, the
passwords revert to the default.
The default username is admin and the default password is extron.
•
• Passwords are case sensitive.
Privacy Notification
figure 12
NAV E 511 Encoder • HTML Operation
Toolbelt
on page 19).
on
18
