Screen Saver Image (see
3
drop-down list to select among the images to display as the
screen saver. Retain Last Frame displays the last frame of
input data before the OSD was activated. Black Screen
shows a black screen. Blue Screen shows a blue screen.
Default Image (Extron) displays the Extron logo. Custom
Image displays an image of your choosing.
NOTES:
• To be available for selection, the custom image must
be manually uploaded into the endpoint (see "Upload a
custom image" below).
• If you select the blue screen as the screen saver, the blue screen itself streams
to the decoder, but any enabled OSD does not. The OSD does output on the
encoder LOOP THRU port (see
• If you have not already uploaded an image, the pane
displays the SELECT FILE button (see
custom image
Upload a custom image
You can upload a custom image to use for the screen saver background as follows:
NOTES:
• A valid custom image must be in the .png file format with a maximum size of 4K
(4096 x 2160).
• The custom image may be cropped but cannot be scaled. For example: if you
upload a 1080p image and the output is 4K, you will see black borders.
On the editable Screen Saver Configuration pane (see
1.
Background Image drop-down list and select Custom Image (see figure 22,
have not already uploaded an image, the pane displays the SELECT FILE button (
1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2
Figure 22. Upload a Custom Image, Steps 1 and 2
2. Click SELECT FILE ( ).
2
figure 21 on page 29) — Click the
on page 6).
B
Upload a
on page 32).
