Each pane has settings that can be changed by clicking the EDIT button (see
on page 24) in the appropriate pane. The selected dialog box opens (see "Stream pane"
below, Loop Thru pane on page 26,
on page 28, Screen Saver pane
page 32).
Stream pane
If you change any of the settings in the Stream Configuration dialog box (see figure 17,
through ), the SAVE button (
1 4
CANCEL ( ) to abandon them. Clicking either button closes the dialog box.
6
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
Figure 17. Stream Configuration Dialog Box
Bitrate — Set the Bitrate in one of three ways:
1
NOTE: Extron recommends leaving the bitrate at the default setting, 850 Mbps.
The bitrate is the rate at which the encoder transmits data. The bitrate affects the
video image quality. Decreasing the bitrate lowers the quality, increasing the bitrate
improves the quality.
• Click and drag the fader control.
Click the and
•
• Directly type a rate into the field.
Video stream — Click to toggle Video Stream on (stream video) and off (do not
2
stream).
NAV Audio Stream — Click to toggle NAV Audio Stream on (stream NAV audio) and
3
off (do not stream).
NOTE: NAV Audio can only be routed to other Extron NAV products. Select NAV
Audio only when your system is interfacing solely with other NAV products and
the audio needs minimal processing.
AES67 Audio Stream — Click to toggle AES67 Audio Stream on (stream AES67
4
audio) and off (do not stream).
NOTE: The AES67 standard allows for interoperability among AES67 capable
devices. Enabling AES67 audio allows the device to transmit a audio stream to a
third-party AES67 capable receiver.
Test Pattern pane
on page 28, and On Screen Display (OSD) pane
) becomes selectable. Click SAVE to take changes or
5
buttons.
