UART Features
Support IrDA
Support ISO7816 Smart Card
Support Manchester coding
For more details, see the UART chapter of the
Manual.

8.24 I2C

The inter-integrated circuit interface (I
other I2C devices on the bus and support the following key features:
• 7-bit and 10-bit addressing mode with multiple 7-bit target addresses
• Multiple-controller transmitter or receiver mode
• Target receiver or transmitter mode with configurable clock stretching
• Support Standard-mode (Sm), with a bit rate up to 100 kbit/s
• Support Fast-mode (Fm), with a bit rate up to 400 kbit/s
• Support Fast-mode Plus (Fm+), with a bit rate up to 1 Mbit/s
– Supported on open drain IOs (ODIO) and high-drive (HDIO) IOs only
• Separated transmit and receive FIFOs support DMA data transfer
• Support SMBus 3.0 with PEC, ARP, timeout detection and host support
• Wakeup from low power mode on address match
• Support analog and digital glitch filter for input signal glitch suppression
• 8-entry transmit and receive FIFOs
For more details, see the I2C chapter of the
Manual.

8.25 SPI

The serial peripheral interface (SPI) peripherals in these devices support the following key features:
• Support ULPCLK/2 bit rate and up to 32Mbits/s in both controller and peripheral mode
• Configurable as a controller or a peripheral
• Configurable chip select for both controller and peripheral
• Programmable clock prescaler and bit rate
• Programmable data frame size from 4 bits to 16 bits (controller mode) and 7 bits to 16 bit (peripheral mode)
• Supports PACKEN feature that allows the packing of 2 16 bit FIFO entries into a 32-bit value to improve CPU
performance
• Transmit and receive FIFOs (4 entries each with 16 bits per entry) supporting DMA data transfer
• Supports TI mode, Motorola mode and National Microwire format
For more details, see the SPI chapter of the
Manual.

8.26 CAN-FD

The controller area network (CAN) controller enables communication with a CAN2.0A, CAN2.0B, or CAN-FD bus
and is compliant to ISO 11898-1:2015 standard supporting up to 5Mbit/s bit rate. Key features of the CAN-FD
peripheral include:
• Full support for 64-byte CAN-FD frames
• Dedicated 1KB message SRAM with ECC
• Configurable transmit FIFO, transmit queue and event FIFO (up to 32 elements)
• Up to 32 dedicated transmit buffers and 64 dedicated receive buffers
1
Only SPI signals on HSIO pins support data rate > 16 Mbits/s; see the Pin Diagrams section for HSIO pins.
Copyright © 2023 Texas Instruments Incorporated
Table 8-14. UART Features (continued)
UART0 (Extend)
Yes
Yes
Yes
MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
2
C) peripherals in these devices provide bidirectional data transfer with
MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
Product Folder Links: MSPM0G3507-Q1 MSPM0G3506-Q1 MSPM0G3505-Q1
MSPM0G3507-Q1, MSPM0G3506-Q1, MSPM0G3505-Q1
UART1 and 2 (Main)
-
-
-
Submit Document Feedback
SLASF88 – OCTOBER 2023
UART3 (Main)
-
-
-
1
