Mixed-signal microcontrollers

Advertisement

Quick Links

1 Features
Core
– Arm
®
32-bit Cortex
protection unit, frequency up to 32MHz
Functional Safety Quality-Managed
– Documentation available to aid in functional
safety system design
Operating characteristics
– Extended temperature: –40°C to 125°C
– Wide supply voltage range: 1.62V to 3.6V
Memories
– Up to 128KB of flash memory with error
correction code (ECC)
Dual-bank with address swap for OTA
updates
– 16KB of SRAM
High-performance analog peripherals
– One 12-bit 1.68Msps analog-to-digital converter
(ADC) with up to 13 total external channels
14-bit effective resolution at 105ksps with
hardware averaging
– Configurable 1.4V or 2.5V internal ADC voltage
reference (VREF)
– Integrated temperature sensor
Optimized low-power modes
– RUN: 106µA/MHz (CoreMark)
– SLEEP: 469µA at 4MHz
– STOP: 52µA at 32kHz
– STANDBY: 1.4µA with RTC and SRAM
retention
– SHUTDOWN: 75nA with IO wake-up capability
Intelligent digital peripherals
– 3-channel DMA controller
– 3-channel event fabric signaling system
– A total of 14 PWM channels supported by:
One 16-bit advanced timer with deadband
support and complimentary outputs,
supporting up to 8 PWM channels
Two 16-bit general-purpose timers, each
with two capture/compare registers
supporting low-power operation in
STANDBY mode
One 16-bit general purpose timer supporting
QEI
– One windowed watchdog timer (WWDT)
– One independent watchdog timer (IWDT)
– RTC with alarm and calendar mode
Enhanced communication interfaces
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. ADVANCE INFORMATION for preproduction products; subject to change
without notice.
MSPM0L111x Mixed-Signal Microcontrollers
®
-M0+ CPU with memory
– Two UART interfaces supporting low-power
operation in STANDBY mode
One extended UART instance supporting
LIN, IrDA, DALI, Smart Card, Manchester
2
– One I
C module supporting up to FM+
(1Mbit/s), SMBus/PMBus, and wakeup from
STOP mode
– One SPI module supporting up to 16Mbit/s
Clock system
– Internal 4 to 32MHz oscillator with ±1.2%
accuracy (SYSOSC)
– Internal 32kHz low-frequency oscillator with
±3% accuracy (LFOSC)
– External 32-kHz crystal oscillator (LFXT)
Data integrity and encryption
– AES-128/256 accelerator with support for GCM/
GMAC, CCM/CBC-MAC, CBC, CTR
– Secure Key Storage for up to two AES keys
– Flexible firewalls for protecting code and data
– True random number generator (TRNG)
– Cyclic redundancy checker (CRCP-16,
CRCP-32)
Flexible I/O features
– Up to 44 GPIOs
Two 5V-tolerant open-drain IOs
Seven high-drive IOs with 20mA drive
strength
One high-speed IO
One Fail-safe IO
Development support
– 2-pin serial wire debug (SWD)
Package options
– 48-pin LQFP (PT) (0.5mm pitch)
– 48-pin VQFN (RGZ) (0.5mm pitch)
– 32-pin VQFN (RHB) (0.5mm pitch)
– 24-pin VQFN (RGE) (0.5mm pitch)
Family members (also see
– MSPM0L1116: 64KB of flash, 16KB of RAM
– MSPM0L1117: 128KB of flash, 16KB of RAM
Development kits and software (also see
and
Software)
– LP-MSPM0L1117 LaunchPad
– MSP Software Development Kit (SDK)
2 Applications
Battery charging and management
Power supplies and power delivery
Personal electronics
Building security and fire safety
Connected peripherals and printers
Energy Infrastructure - Smart Metering
MSPM0L1117, MSPM0L1116
SLASFC9 – DECEMBER 2024
Device
Comparison)
Tools
development kit
