8.16 DAC

The 12-bit buffered digital-to-analog converter (DAC) in these devices converts a digital input value into an
analog voltage to a buffered output channel and it supports the following key features:
Up to 1-Msps output sampling rate
8-bit or 12-bit voltage-output resolution
Self-calibration option for offset error correction
Straight binary or twos-complement data format
Integrated sample time generator for generation of predefined sampling rates
Integrated FIFO and support DMA operation
One hardware trigger from event fabric for conversion
Programmable voltage reference options:
– Supply voltage (VDD)
– External reference voltage (VREF IO)
– Internal reference voltage (1.4V, 2.5V)
For more information about device analog connections, see
For more details, see the DAC chapter of the
Manual.

8.17 OPA

The zero-drift op amps (OPAs) in these devices, OPA0 and OPA1, are chopper stabilized operational amplifiers
with rail-to-rail input/output and a programmable gain stage feedback loop.
The OPA peripherals support the following key features:
Software-selectable zero-drift chopper stabilization for improved accuracy and drift performance
Factory trimming to remove offset error
Burnout current source (BCS) integrated to monitor sensor health
Programmable gain amplifier (PGA) up to 32x
The OPA features configurable input muxes P-MUX, N-MUX, and M-MUX to support various analog signal chain
amplifier configurations that include general purpose, inverting, noninverting, unity gain, cascade, noninverting
cascade, difference, and more. The following tables list the input channel mapping for each OPA.
PSEL
P-MUX INPUTS
0x0
Open
0x1
OPA0_IN0+
0x2
OPA0_IN1+
0x3
DAC_OUT / OPA0_IN2+
0x4
DAC8.0_OUT
0x5
VREF
0x6
OPA1_RTOP
0x7
GPAMP Output
0x8
GROUND
PSEL
P-MUX INPUTS
0x0
Open
0x1
OPA1_IN0+
64
Submit Document Feedback
MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
Table 8-12. OPA0 Input Channel Mapping
NSEL
0x0
0x1
0x2
(1)
0x3
0x4
0x5
Table 8-13. OPA1 Input Channel Mapping
NSEL
0x0
0x1
Product Folder Links:
MSPM0G3507-Q1 MSPM0G3506-Q1 MSPM0G3505-Q1
Section
8.30.
Section
8.30.
N-MUX INPUTS
Open
OPA0_IN0-
OPA0_IN1-
OPA1_RBOT
RTAP
RTOP
N-MUX INPUTS
Open
OPA1_IN0-
www.ti.com
MSEL
M-MUX INPUTS
0x0
Open
0x1
OPA0_IN1-
0x2
GND
0x3
DAC_OUT / OPA0_IN2+
0x4
OPA1_RTOP
MSEL
M-MUX INPUTS
0x0
Open
0x1
OPA1_IN1-
Copyright © 2023 Texas Instruments Incorporated
