MSPM0G310x Mixed-Signal Microcontrollers with CAN-FD Interface

1 Features

Core
– Arm
®
32-bit Cortex
®
protection unit, frequency up to 80 MHz
Operating characteristics
– Extended temperature: –40°C up to 125°C
– Wide supply voltage range: 1.62 V to 3.6 V
Memories
– Up to 128KB of flash memory with built-in error
correction code (ECC)
– Up to 32KB of ECC protected SRAM with
hardware parity
High-performance analog peripherals
– Two simultaneous sampling 12-bit 4-Msps
analog-to-digital converters (ADC's) with up to
11 external channels
14-bit effective resolution at 250-ksps with
hardware averaging
– One general-purpose amplifier (GPAMP)
– Configurable 1.4-V or 2.5-V internal shared
voltage reference (VREF)
– Integrated temperature sensor
Optimized low-power modes
– RUN: 96 µA/MHz (CoreMark)
– SLEEP: 458 µA at 4 MHz
– STOP: 47 µA at 32 kHz
– STANDBY: 1.5 µA with RTC and SRAM
retention
– SHUTDOWN: 78 nA with IO wakeup capability
Intelligent digital peripherals
– 7-channel DMA controller
– Two 16-bit advanced control timers supporting
dead band insertion and fault handling
– Seven timers supporting up to 22 PWM
channels
One 16-bit general purpose timer
One 16-bit general purpose timer supports
QEI
Two 16-bit general-purpose timers support
low-power operation in STANDBY mode
One 32-bit general-purpose timer
Two 16-bit advanced timers with deadband
– Two window-watchdog timers
– RTC with alarm and calendar mode
Enhanced communication interfaces
– Four UART interfaces; one supports LIN,
IrDA, DALI, Smart Card, Manchester, and
three support low-power operation in STANDBY
mode
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. ADVANCE INFORMATION for preproduction products; subject to change
without notice.
-M0+ CPU with memory
MSPM0G3107, MSPM0G3106, MSPM0G3105
SLASF12A – FEBRUARY 2023 – REVISED JUNE 2023
2
– Two I
C interfaces supporting up to FM+
(1 Mbit/s), SMBus/PMBus, and wakeup from
STOP mode
– Two SPI interfaces, with one SPI interface
supporting upto 32Mbits/s
– One Controller Area Network (CAN) interface
supports CAN 2.0 A or B and CAN-FD
Clock system
– Internal 4- to 32-MHz oscillator with upto ±1.2%
accuracy (SYSOSC)
– Phase-locked loop (PLL) up to 80 MHz
– Internal 32-kHz oscillator (LFOSC)
– External 4- to 48-MHz crystal oscillator (HFXT)
– External 32-kHz crystal oscillator(LFXT)
– External clock input
Data integrity and encryption
– Cyclic redundancy checker (CRC-16, CRC-32)
– True random number generator (TRNG)
– AES encryption with 128 or 256-bit key
Flexible I/O features
– Up to 28 GPIOs
Two 5-V tolerant IOs
Two high-drive IOs with 20-mA drive
strength
Development support
– 2-pin serial wire debug (SWD)
Package options
– 32-pin VQFN
– 28-pin VSSOP
– 20-pin VSSOP
Family members (also see
– MSPM0G3105: 32KB flash, 16KB RAM
– MSPM0G3106: 64KB flash, 32KB RAM
– MSPM0G3107: 128KB flash, 32KB RAM
Development kits and software (also see
and
Software)
LP-MSPM0G3507 LaunchPad
kit
– MSP Software Development Kit (SDK)

2 Applications

Motor control
Home appliances
Uninterruptible power supplies and inverters
Electronic point of sale systems
Medical and healthcare
Test and measurement
Factory automation and control
Industrial transport
Grid infrastructure
Smart metering
Device
Comparison)
Tools
development
