8.6 Events

The event manager transfers digital events from one entity (for example, a peripheral) to another (for example, a
second peripheral, the DMA, or the CPU). The event manager implements event transfer through a defined set
of event publishers (generators) and subscribers (receivers) which are interconnected through an event fabric
containing a combination of static and programmable routes.
Events that are transferred by the event manager include:
• Peripheral event transferred to the CPU as an interrupt request (IRQ) (Static Event)
– Example: RTC interrupt is sent to the CPU
• Peripheral event transferred to the DMA as a DMA trigger (DMA Event)
– Example: UART data receive trigger to DMA to request a DMA transfer
• Peripheral event transferred to another peripheral to directly trigger an action in hardware (Generic Event)
– Example: TIMx timer peripheral publishes a periodic event to the ADC subscriber port, and the ADC uses
the event to trigger start-of-sampling
Refer to the Event chapter of the
more information.
A generic route is either a point-to-point (1:1) route or a point-to-two (1:2) splitter route in which the peripheral publishing the
event is configured to use one of several available generic route channels to publish its event to another entity (or entities, in
the case of a splitter route), where an entity may be another peripheral, a generic DMA trigger event, or a generic CPU event.
