10 Technical data
Display elements
Operating elements
Remote operation
Ex approval
CE approval
Certification
PROFIBUS-PA
Other standards and
guidelines
150
10.1.9

Human interface

x Liquid crystal display: back-lit, four lines with 16 characters
x Custom configurations for presenting different measured value and status variables
x 3 totalizers
x Local operation with three optical sensor keys (–, +, E)
x Application-specific Quick Setups for quick and easy commissioning
Operation via PROFIBUS-DP/-PA

10.1.10 Certificates and approvals

Information about currently available Ex versions (ATEX, FM, CSA) can be supplied by
your E+H Sales Centre on request. All explosion protection data are given in a separate
documentation which is available upon request.
The measuring system is in conformity with the statutory requirements of the EC
Directives.
Endress+Hauser confirms successful testing of the device by affixing the CE mark.
The Prosonic Flow 93 flowmeter has passed all the test procedures implemented and
has been certified and registered by the PNO (PROFIBUS User Organisation). The
flowmeter thus meets all the requirements of the specifications listed below:
x Certified for PROFIBUS-PA, Profile Version 3.0
Device certification number: available upon request
x The device may also be operated using certified devices from other manufacturers
(interoperability).
EN 60529:
Degrees of protection by housing (IP code)
EN 61010
Protection Measures for Electrical Equipment for Measurement, Control, Regulation and
Laboratory Procedures.
EN 61326/A1 (IEC 1326) "Emmision to class A requirements"
Electromagnetic compatibility (EMC requirements)
NAMUR NE 21
Electromagnetic compatibility (EMC) of imdustrial process and laboratory control equip-
ment.
MAMUR NE 43
Standardisation of the signal level for the breakdown information of digital transmitters
with analogue output signal.

10.1.11 Ordering information

The E+H service organisation can provide detailed ordering information and information
on the ordering codes on request.
PROline Prosonic Flow 93 PROFIBUS-DP/-PA
Endress+Hauser
